Oakworks USWI Women’s Imaging Ultrasound Table

Ships in typically 3-4 weeks

Brand New
SKU VM-E08M57125 Category

The Oakworks USWI Women’s Imaging Ultrasound Table is a full-featured 3-section table designed for all women’s imaging modalities. Featuring a 550lb bariatric capacity, dynamic 22″–38″ height range, and electric Fowler, it exceeds sonography industry standards. Its sleek base and twin-tower design ensure superior ergonomic access and patient stability.

Warranty Included
On all products
25+ Years in Business
Trusted since 1998
Lifetime Support
We're always here to help

Description

Oakworks USWI Women’s Imaging Ultrasound Table. Oakworks has been providing customers with innovative medical equipment, excellent service, and cost-effective solutions for over 30 years. Additionally, collaborating with leaders in the medical specialties resulted in cutting-edge table designs and patient positioning devices.

Furthermore, Oakworks Medical is ISO 13485:2003 certified. As a result, customers can trust the table’s quality and build. Moreover, this USWI Women’s Imaging Ultrasound Table features a full 3-section top for all women’s imaging needs. Additionally, the twin tower design adds strength, while the sleek base works cleanly with ultrasound equipment.

Oakworks USWI Women’s Imaging Ultrasound Table Key Features

  • 22″–38″ Adjustable Height Range
  • 550 lb Bariatric Lift Capacity
  • Hand-Controlled Trendelenburg and Reverse Trendelenburg
  • Electric Fowler
  • 3″ Comfort Padding System (21 Color Options)



Overall, these features work together to give sonographers reliable, ergonomic working conditions during procedures. Furthermore, leading ergonomic specialists designed this table, which exceeds industry standards for sonography and carries an industry-leading 3-year warranty. Moreover, the table is FDA listed, ETL approved, and CE marked. In addition, see tabs for more information on the USWI Ultrasound Table.



Curious how our refurbishing process works? Check out “Doing It Right: Our Refurbishment Process” in Venture Medical’s Equipment Knowledge Center.

Looking for other New and Refurbished Imaging Tables? Click here to view our New and Refurbished Imaging Tables.

Do you need replacement pads for your imaging tables? Click here to view our Imaging Table Replacement Pads.

  • Full-featured 3-section tabletop design for all Women’s Imaging ultrasound modalities
  • Designed by leading Ergonomic Specialists and exceeds industry standards for Sonography
  • Industry-leading 3-year warranty
  • 21 beautiful fabric colors available
  • Dynamic 22″ to 38″ adjustable height range for safe wheelchair transfer and ergonomic working heights
  • 550 lb bariatric-rated lift and load capacity
  • Twin tower design for added strength and rigidity
  • The sleek base design promotes unobstructed compatibility with ultrasound equipment ensuring better ergonomic conditions for the sonographer
  • Super comfortable 3″ padding system
  • Trendelenburg and Reverse Trendelenburg
  • 4″ (10cm) Locking Casters
  • Adjustable access back support (right) 0-85°
  • Paper Roll Holder (paper not included)
  • Stirrups (Retractable Foot Rests)
  • Table Top Width: 27″ (also available in 30″Width, see Options)
  • FDA Listed, ETL Approved, CE Marked
  • 3 Section Top
  • Bariatric Lift/Load Capacity: 550 lbs.
  • Height Range: 22″- 38″
  • Width: 27″
  • Length: 72″
  • Top Dimensions: Fowler – 34″, Seat – 24″, Foot – 13″
  • Motions: Trendelenburg / Reverse ±15º
  • Standard Controls: 3 motion hand
  • Manual 4 position Leg Rest Footrest
  • Padding: 3″ multi-layer
  • Upholstery: TerraTouch  (PVC-Free)
  • Table Weight: 359 lbs
  • Warranty: 3 years parts, 1-year labor
  • Certifications: FDA listed, cETL approved, CE marked
  • 27″W Table P/N: 66127
  • 30″W Table P/N: 61848

To View Oakwork’s Available Upholstery Colors with Names view the image in the Gallery above.

Please Note:  We strive to ensure that the colors displayed on our product imagery (online and in print) are as accurate as possible. However, due to the limitations of printers, scanners, computer monitors, and other equipment, the colors may not be accurate.

Oakworks USWI Women’s Imaging Ultrasound Table Brochure (click to view)

Women’s Imaging Ultrasound Table Video  (click to view)

Unsure which model or features are best suited to your operating theater? Here at Venture Medical, we have a large selection of new and completely refurbished imaging tables. Choose from models built for specific procedures, weight capacity, tilt and lateral tilt range, radiolucent tabletops, and more.

Contact Us Today for Questions and Available Options that are best suited to Fit Your Specific Needs and Budget!
