Oakworks DTPM300 Imaging Table | Rectangular Top

product ID VM-E08M57113

If you need the Oakworks DTPM300 Imaging Table with Rectangular Top you don’t need to look any further. Give us a call or request a quote and let us help you.

Add to wishlist
Add to quote
SKU: VM-E08M57113 Category:

If you need the Oakworks DTPM300 Imaging Table with Rectangular Top you don’t need to look any further. Give us a call or request a quote and let us help you.

Product Description:

Oakworks® DTPM300 Imaging Table is ideal for pain management treatment centers, surgical centers, and other multi-disciplinary medical facilities where a cost-sensitive solution without compromise is needed.  Oakworks has been providing customers with innovative medical equipment, excellent service, and cost-effective solutions for over 30 years.

The Oakworks DTPM300 Imaging Table Features 3 Movement Imaging Table and Electronic Height Range from 24″ to 40″ along with a 40″ Open Space between Towers.  The Manual Traveling Top has an overall 23″ travel. Additional features include Trendelenburg & Reverse Trendelenburg, Manual Motion with 23″ maximum longitudinal travel, and a radiolucent top. It has a 6″ trail and a patient weight capacity of 450 lbs. Additionally, it is compatible with all major C-arm products.

Accessories included:

  • 1″ Radiolucent Table Top Pad

Oakworks Medical has collaborated with leaders in the medical specialties we serve to create cutting-edge table designs and patient positioning devices that balance the needs of both patients and practitioners.

See tabs for more information.

  • Most Cost-effective 3 Movement Imaging Table
  • 2 Powered Motions / 1 Manual Motion
  • Powered Motions: Height, Powered Trendelenburg tilt
  • Manual Motion: 23″ maximum Longitudinal travel
  • +14°/-14° Trendelenburg and reverse Trendelenburg tilt
  • 23″ manual longitudinal travel
  • 24″x78″ Radiolucent Top
  • Robust Dual Lift Tower Design with 40″ distance between towers
  • Best Height Range of 24″ to 40″
  • 6″ Trail
  • Patient Weight Capacity: 450 lbs.
  • Compatible with all major C-arm products
  • Warranty
  • Electronic Height Range: 24″- 40″
  • Widths: 24″
  • Length: 78″
  • Patient Weight Capacity: 450 lbs
  • Weight: 390 lbs.
  • Trendelenburg & Reverse Trendelenburg: Tilt +14°/-14°
  • Manual Traveling Top: 23″ Overall travel
  • Controls: 1 foot control & 1 hand control
  • Warranty: 3 years parts, 2 years labor
  • P/N: 61252-T01

Oakworks DTPM300 Brochure  (click to view)

Available Options Sold Separately:

  • 2″ Radiolucent Table Top Pad
  • Carbon Fiber Arm Board
  • Fluoro Extender
